| Article number | 3210.0485 |
|---|---|
| Catalog number | DLE 2-1-2-GG |
| Outlet pressure max. | 40 bar (580 psi) |
| Pressure ratio | 1:4 |
| Number of air drive pistons | 2 |
| Article number | 3210.0485 |
|---|---|
| Catalog number | DLE 2-1-2-GG |
| Outlet pressure max. | 40 bar (580 psi) |
| Pressure ratio | 1:4 |
| Number of air drive pistons | 2 |
| Mode of action | Single-acting |
| Gas inlet pressure min. | 0 bar (0 psi) |
| Gas inlet pressure max. | 40 bar (580 psi) |
| Min. Drive pressure | 1 bar |
| Max. Drive pressure | 10 bar |
| Booster options | Standard |
| Air drive inlet PL | 12B - 3/4 BSPP with seal outside |
| Inlet A | 8B - 1/2 BSPP with seal outside |
| Outlet B | 8B - 1/2 BSPP with seal outside |
| ATEX Directive | II 2G Ex h IIB T4 Gb X |
| Dimensions (L x W x H) approx. | 611 x 181 x 272 mm |
| Weight approx. | 26 kg |
Unfortunately, there are currently no files available for the selected article number. Please use the contact form to send a request or ask for more information.
If you need additional spare/wearing parts for the selected product or products already in use, please contact us.
 |
Seal kit spoolArticle number 3620.0102 Recommended Quantity 1 Schematic VP15.01.00 |
|---|---|
|
Seal kit HPArticle number 3630.0128 Recommended Quantity 1 Schematic VP16.02.04 |
|
Seal kit airArticle number 3630.1011 Recommended Quantity 1 Schematic VP16.02.40.01 |
|
Replacement kit valvesArticle number 3630.1175 Recommended Quantity 1 Schematic VP16.08.70 |
