| Article number | 3210.0154 |
|---|---|
| Catalog number | DLE 30-75-2-GU-ZK-30 |
| Outlet pressure max. | 2,100 bar (30,450 psi) |
| Pressure ratio | 1:60 / 1:150 |
| Number of air drive pistons | 2 |
| Article number | 3210.0154 |
|---|---|
| Catalog number | DLE 30-75-2-GU-ZK-30 |
| Outlet pressure max. | 2,100 bar (30,450 psi) |
| Pressure ratio | 1:60 / 1:150 |
| Number of air drive pistons | 2 |
| Gas inlet pressure min. | 15 bar (218 psi) |
| Gas inlet pressure max. | 2,100 bar (30,000 psi) |
| Min. Drive pressure | 1 bar |
| Max. Drive pressure | 10 bar |
| Booster options | Intercooler between the two stages of a two stage booster |
| Air drive inlet PL | 12B - 3/4 BSPP with seal outside |
| Inlet A | 4B - 1/4 BSPP with seal outside |
| Outlet B | 9/16-18UNF (4H - incl. Collar & Gland) |
| ATEX Directive | II 2G Ex h IIB T4 Gb |
| Dimensions (L x W x H) approx. | 826 x 272 x 233 mm |
| Weight approx. | 29 kg |
Unfortunately, there are currently no files available for the selected article number. Please use the contact form to send a request or ask for more information.
If you need additional spare/wearing parts for the selected product or products already in use, please contact us.
 |
Seal kit spoolArticle number 3620.0102 Recommended Quantity 1 Schematic VP15.01.00 |
|---|---|
|
Seal kit HPArticle number 3630.3096 Recommended Quantity 1 Schematic VP16.02.34.08 |
|
Replacement kit valvesArticle number 3630.4490 Recommended Quantity 1 Schematic VP16.02.52.08 |
